BOOTMOD3 B58 TUNE

World's First, Most Advanced and Widely Adopted cloud-based flash tuning platform for the BMW F and G series vehicles.

Cloud-based solution with a web-based interface for use with a laptop or with our mobile apps built for iOS and Android! Developed and tested in-house from the ground up since its debut in November 2016 with new features and updates being added regularly makes the bootmod3 platform a custom BMW factory DME tuning solution like no other on the market since.

Build the ultimate tune for your B58 engine powered vehicle and go from stock to full race calibration, and everywhere in between, with a map switch in the provided mobile app. bootmod3 calibrates the factory vehicle modules over the OBD port in a matter of minutes in the convenience of your driveway or anywhere internet access is available.

Stage 1 91 octane: up to 18% HP / 26% TQ
Stage 1 93 octane: up to 20% HP / 26% TQ
Stage 1 E30 octane: up to 25% HP / 30% TQ
Stage 2 91 octane: up to 24% HP / 32% TQ
Stage 2 93 octane: up to 26% HP / 32% TQ
Stage 2 E30 octane: up to 30% HP / 35% TQ
Stage 2 Racegas: up to 30% HP / 35% TQ
Stage 2+ 91 octane: up to 37% HP / 62% TQ
Stage 2+ 93 octane: up to 43%HP / 68% TQ
Stage 2+ E30 octane: up to 47%HP / 73% TQ
Stage 2 AGG (Aggressive burble) versions of maps available
Based on NON-MPPK version cars

B58-D Engine Vehicles (2020+ G20 M340, X3 M40i, X4 M40i)
Stage 1 91 octane: up to 18% HP / 28% TQ
Stage 1 93 octane: up to 21% HP / 30% TQ
Stage 1 E30 octane: up to 28% HP / 34% TQ
Stage 2 91 octane: up to 22% HP / 33% TQ
Stage 2 93 octane: up to 25% HP / 35% TQ
Stage 2 E30 octane: up to 31% HP / 38% TQ
Stage 2 AGG (Aggressive burble) versions of maps available
Based on NON-MPPK version cars

bootmod3 app and cloud services offer many unique features not found in any other flash tune including and currently available:

Mobile app (iOS and Android) and Web (http://www.bootmod3.net) including Windows and macOS support
One OTS map/tune included with the purchase and any other maps labeled as "FREE"
Datalogging hundreds of diagnostic channels, up to 70+ channels concurrently with the highest throughput and sample rates available
Datalog sharing and charting without a need to upload to 3rd party websites or apps using the mobile app or web browser
Cloud-based storage for map data and datalogs
Ability to log any internal RAM variable values with a number of preset ones available
Reverting back to stock performance map and re-locking the DME to stock programming
Live Dash - realtime vehicle parameter monitoring via in-app gauges
Diagnostics
Read and clear trouble codes in all vehicle modules
Reset learned adaptations (octane, knock, Valvetronic, etc)
ECU power reset
(Optional) Off the shelf (OTS) tunes for 91/93/Race gas/E85 octane (SEE HERE)
(Optional) Custom tuning available through tuners in the bootmod3 Tuner Directory. bootmod3 contains a full map editor so you can tune your car yourself or with your local tuner of choice as well.

Some of the OTS and possible aftermarket turbo upgrade custom map features provided by the bootmod3 platform:

Map Customization through Map Editor
Exhaust Burble adjustments on any map (OTS & Custom)
GTS Startup Roar
Max Cooling Mode
Cold start (cat heating on startup) removal for quieter cold start
Cat efficiency check (CEL) removal for de-cat downpipes (for off-road use)
Exhaust Flap Adjustments (Sport Mode)
Top Speed Limiter Removal
Electronic Wastegate (EWG) Disable
Custom High-Pressure Fuel Pump Settings
Exhaust OPF/PPF/GPF Removal
Boost By Gear % Reduction
Re-calibrated Sport Gauges on iDrive
Maps for upgraded turbos
E85/blend, RaceGas, and Meth Injection Tuning
Custom Throttle Mapping
Backend Flash Maps for Piggyback Use

B58 engine BMW Vehicles supported (if your B58 vehicle is not listed please inquire with us):

For more info take a look at the FAQ here!

*** OBD ENET cable required, available separately (Amazon $20)

*** Vehicles with November 2019+ software may require DME unlock done on the bench to enable OBD flashing. If you have the November 2019+ software update, feel free to contact support@protuningfreaks.com for details

*** bootmod3 OBD WiFi Adapter device is not required to use the bootmod3 platform. It is a convenient option that removes the need for using a laptop in the car when using bootmod3's features.

***Direct ENET Cable connection to an iOS or Android device without having to use the BM3 WiFi Adapter. For more information please email us at sales@protuningfreaks.com or refer to our Instagram and Facebook accounts.

VEHICLE MANUFACTURER WARRANTY AND EMISSIONS DISCLAIMER

Some items used and/or installed by PRO TUNING FREAKS may void portions of your vehicle’s factory warranty. Some items may not be legal for “on highway use”. PRO TUNING FREAKS makes no guarantees to the legality of any parts used for “on highway vehicles” and accepts no responsibility for compliance with the vehicle’s factory warranty.
